MS-33B

Input Sensitivity: MM≤4mV, MC≤0.3mV
Output Voltage: 0.5v (1KHz)
Total harmonic distortion (Distortion): MM ≤0.2% MC ≤0.5%
Frequency Response (Frequency Response): in line with RIAA standard features
Signal-to-noise ratio (SNR): MM ≥63dB (A weighting), MC ≥53dB (A weighting)
Tube: 12AX7/ECC83×2, 12AU7/ECC82×1
Stylus type (Phono Stage Suitability): either MM or MC
MC·HI-Z is suitable for MC Phono Amplifier with impedance ≥50Ω (MC.HI-Z: ≥50Ω MC Phono Amplifier)
MC·Low-Z Suitable for MC Phono Amplifier with impedance <50Ω (MC.Low-Z: <50ΩMC Phono Amplifier)
Net weight (N.W): 5.4kg
Gross weight (G.W): 7.1kg
Size: Depth (L) 290mm × width (W) 320mm × height (H) 105mm
Outer packaging (Package): length (L) 460mm × width (W) 360mm × height (H) 195mm

Consultation

yaqin@fsyaqin.com

Details display

: MS-33B

: MS-33B

: MS-33B

Test report

: 3C certification

: CE certificate

: Get good title

: 2012 hifi audio Awards

Our Core Advantages

Industry experience

01

27 years of experience in the production of tube power amplifiers ；OEM for many well-known brands, products are sold to more than 40 places at home and abroad

Quality Assurance

02

Passed 3C certification, CE certification, CB certification, in line with HIFI standards,
and won a number of HIFI audio awards

Prompt Delivery

03

The company has a 5000㎡ production workshop, 7 automated production
lines, which are equipped with metal casing stamping processing, CNC numerical control processing, transformer production and product assembly workshops, etc.

After-sales Service

04

Implement "three guarantees" after-sales service, free guidance for use
One year warranty for switchboard and ten years for transformer

Hot product recommendation

: MS-88

Maximum output power: 50W*2 (8 ohms, ultra linear, 1KHz, THD=5%) 25W*2 (8 ohms, tri-pole, 1KHz, THD=5%) Total harmonic distortion: ≤1% (at 35W output, 1KHz) Signal-to-noise ratio: ≥91dB (A-weighted) Input sensitivity: ≤300mV Frequency response: 10Hz~75KHz (-2dB) Load impedance: 4Ω or 8Ω Maximum power consumption: 300W Electronic tube: KT-88*4, USSR 6H8C*2, ECC83/12AX7*1 Gross weight approx.: 27.5kg Net weight approx.: 24kg Dimensions: W400mm H219mm D363mm

了解详情

: MS-34B

Output Power：UL38W×2（8Ω） Frequency Response：10Hz--48KHz（-2dB） Distortion：≤1.0% SNR：≥90dB（A） Input Sensitivity：Intergrated：≤260mV Maximum Power Consumption：≤250W Tube：EL34 x 4 6N8P x 2 6N9P x 1 Gross Weight：about 25.5 kg Size：（W）400mm（D）355mm（H）220mm

了解详情

: MC-100B

Output Power: 25W+25W (8Ω) three-pole (TR) connection 50W+50W (8Ω) ultra-linear (UL) connection Frequency response: 5Hz-80KHz (-2dB) Distortion: ≤0.5% (at 35W) Signal to noise ratio: ≥91dB (A) Input sensitivity: combined type ≤ 0.25V Maximum power consumption: ≤370W Electronic tube: KT88×4 6N8P×4 12AX7B×2 Gross weight: about 31 kg

了解详情

: MS-84L

Output power: 2x12W (4Ω-8Ω) Harmonic distortion: ≤2% Signal to noise ratio: ≥80db (A) Frequency response: 6HZ-90KHz Input sensitivity: 250mV Input signal level: ≤300mv Maximum power consumption: ≤90W Tube: 6P14*4 12AX7B*2

了解详情

: MC-13S

Output power: 40W + 40W (8Ω) Distortion: ≤0.9%(28W) Frequency response: 10Hz -76KHz (-2dB) Signal to noise ratio: ≥85dB (A weighting) Power consumption: ≤220W Sensitivity: ≤0.26V Electronic tube: EL34×4 or 6CA7T×4 12AT7×4 Gross weight: 22Kg Volume: length 470mm × width 315mm × height 175mm

了解详情

: MS-88

Maximum output power: 50W*2 (8 ohms, ultra linear, 1KHz, THD=5%) 25W*2 (8 ohms, tri-pole, 1KHz, THD=5%) Total harmonic distortion: ≤1% (at 35W output, 1KHz) Signal-to-noise ratio: ≥91dB (A-weighted) Input sensitivity: ≤300mV Frequency response: 10Hz~75KHz (-2dB) Load impedance: 4Ω or 8Ω Maximum power consumption: 300W Electronic tube: KT-88*4, USSR 6H8C*2, ECC83/12AX7*1 Gross weight approx.: 27.5kg Net weight approx.: 24kg Dimensions: W400mm H219mm D363mm

了解详情
